COTS-Plus – TCB Conductive Polymer

Features & Benefits

Robust design for long operation lifetime
Statistical screening with Accelerated Ageing
Surge testing level option
Improved basic reliability
Operating Temperature: -55 to +125°C
Shock & vibration from MIL-STD-202
3x reflow cycles according to J-STD-020

Typical Applications

AC/DC Power Supplies
DC/DC Convertors
Military
Filtering
Decoupling
Timing Circuits
Pulsing Circuits

TCB is a COTS Plus conductive polymer series designed for use in demanding industrial applications requiring very low ESR with stable, high frequency capacitance retention and longer life performance – such as high power DC/DC converters employed in industrial, avionics and special reliability required applications. Additional reliability/surge screening and SnPb plating optional upon request.

Datasheet / Catalog
